Haute-Sorne, Switzerland

The Haute-Sorne Project will begin in 2017 with drilling Glovelier-1 (GVL-1), the first of a 2-well geothermal doublet connected through an EGS. Once completed, water will be circulated between the two wells, in a closed-loop system used for power generation. GVL-1 will also prove the feasibility of the Geo Energie Suisse downhole heat exchanger concept.

GVL-1 will be drilled to a total vertical depth of 5 000 m. The final bottom hole static temperature (BHST) must be a minimum of 170  °C. The well will be drilled vertically until the top of the granite basement is reached. Then it will be steered to intersect a maximum number of natural fissures and deviated to 55° from vertical.

The injection/production drain will not be cased. The open hole drained will be sectioned with a completion string using water swelling elastomer and slickline operated mechanical sleeves. The planned completion design calls for 30 individual sections spread over a 1 500 m long drain. Each section will be stimulated independently by injecting defined volumes of fresh water, according to a pumping sequence yet to be defined. An extensive seismic monitoring programme is planned, that will take place before, during and after the drilling, completion and stimulation operations.

Operator operator-logo

Geo Energie Suisse

Work Package No

5

Location

Haute-Sorne, France

Construction Year

Start drilling in 2017

Foreseen Stimulation Techniques stimulation-logo

Multi-stage shear stimulation

Type of Use

Provision of electricity

Soil Condition

Granite

Production Horizon

not known yet

Upper Depth (m)

5000

Thickness (m)

1700

T (°C)

170

Salinity (g/l)

no data available

Contact
Dr. Peter Meier (CEO)
Geo-Energie Suisse AG
Reitergasse 11
8004 Zürich
Switzerland
Phone: +41 (0)79 248 48 65
E-mail: p.meier@geo-energie.ch
http://www.geo-energie.ch
